The 2.8 inch TFT LCD Touch Display is fully assembled, tested and ready to go. Add the touch display without wiring, no soldering! Simply plug it in and load up a library – you’ll have it running in under 10 minutes! Works best with any classic Arduino ATMEGA328 Board

So spice up your Arduino UNO project with a beautiful large touchscreen display shield with a built-in microSD card connection. This TFT display is big (2.8″ diagonal) bright (4 white-LED backlights) and colorful (18-bit 262,000 different shades)!

The Display comes with 240×320 pixels with individual pixel control. It has way more resolution than a black and white 128×64 display.  As a bonus, this display has a resistive touchscreen attached to it already, so you can detect finger presses anywhere on the screen.


Features:

  • 2.8 Inch diagonal LCD TFT display, with bright 4 white-LED backlights, default state: on
  • It can control the backlight to connect the transistor to a digital pin
  • 240×320 Pixels, with colorful and 18-bit, 262,000 different kinds of shade
  • 4-wire resistive touchscreen
  • 8-bit digital interface, plus 4 control lines


Specifications:

  • Driver : HX8347i
  • Backlight Color : White
  • Screen Resolution : 240×320
  • Screen Size : 2.8 inch
  • Touch Type  : Resistive
  • Length (mm) : 78
  • Width  (mm) : 53
  • Height (mm) : 15
  • Weight (gm) : 45


Package Includes:

1 x 2.8 Inch TFT LCD Shield Touch Screen Module 320x240 Support UNO MEGA2560

1 x Stylus

Brand/Manufacturer
Country Of Origin
Packer / Importer Address Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India.
MRP Rs. 1167.02 (Inclusive of all Taxes)
Write a review
Please login or register to review

* Product Images are shown for illustrative purposes only and may differ from actual product.

2.8 Inch TFT LCD Shield Touch Screen Module 320x240 Support UNO MEGA2560

  • Product Code: EC-10023
  • Availability: Out Of Stock
  • Rs.989.00
  • (Excluding 18% GST)
