Barometric Pressure Unit is a barometer unit, which uses a Bosch bmp280 pressure sensor to measure atmospheric pressure and estimate altitude. The relative accuracy can reach 0.12hpa, equivalent to 1m height difference. At the same time, the temperature drift coefficient is very low, which can reach 1.5 PA / K, that is, the temperature drift is 12.6 cm / K. in addition, there is an integrated temperature sensor in the chip.


Applications:
  1. Wearable devices
  2. Motion tracking
  3. UAV attitude determination

Features:

  1. Air pressure sensor, with a temperature sensor on-chip, can be measure simultaneously
  2. The accuracy is 0.12hpa
  3. Temperature drift coefficiency 1.5pa/k
  4. Supports periodic measurement
  5. Internal integrated 5-segment filter
  6. Support low power consumption
  7. Development platform: Arduino, uiflow (Blockly, Python)
  8. 2x LEGO compatible holes

Package Includes:

1x Barometric Pressure Unit

1x Grove Cable(5cm)



Specifications :-

Air Pressure Measurement Range

300 1100 hPa(+9000m ~ -500m)

Absolute Accuracy

1hPa

Relative Accuracy

0.12hPa

Temperature Measurement Range

-40 ~ +85C

Temperature Resolution

0.01C

Pressure Resolution

0.16Pa

Temperature Coefficient Offset

1.5 Pa/K(12.6 cm/K)

Current Consumption

2.7A @ 1 Hz sampling rate

Length (mm)

24

Width (mm)

24

Height (mm)

13

Weight (gm)

8




Brand/Manufacturer Generic
Country Of Origin China
Packer / Importer Address Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India.
MRP Rs. 400.02 (Inclusive of all Taxes)
