  • 4N36 Optocoupler Phototransistor IC DIP-8 Package

4N36 optocoupler consists of gallium arsenide infrared LED and a silicon NPN photo transistor. These couplers are Underwriters Laboratories (UL) listed to comply with a 5000 VRMS isolation test voltage. This isolation performance is accomplished through double molding isolation manufacturing process. Comliance to DIN EN 60747-5-5 partial discharge isolation specification is available for these families by ordering option 1. These isolation processes and the ISO9001 quality program results in the highest isolation performance available for a commecial plastic phototransistor optocoupler. The devices are available in lead formed configuration suitable for surface mounting and are available either on tape and reel, or in standard tube shipping containers.


  • Isolation test voltage 5000 VRMS
  • Interfaces with common logic families
  • Input-output coupling capacitance < 0.5 pF
  • Industry standard dual-in-line 6 pin package
  • Compliant to RoHS directive 2002/95/EC and in accordance to WEEE 2002/96/EC


  • AC mains detection
  • Reed relay driving
  • Switch mode power supply feedback
  • Telephone ring detection
  • Logic ground isolation
  • Logic coupling with high frequency noise rejection


  • UL file no. E52744 (pending)
  • cUL tested to CSA 22.2 bulletin 5A
  • DIN EN 60747-5-2 (VDE 0884)/DIN EN 60747-5-5
  • (pending), available with option 1
  • BSI: EN 60065, EN 60950-1
  • CQC


VRReverse voltage6V
IFForward current60mA
IFSMSurge current2.5A
PdissPower dissipation70mW
VCEOCollector-emitter breakdown voltage70V
VEBOEmitter-base breakdown voltage7V
ICCollector current50mA

Package Includes:-

1 x 4N36 Optocoupler Phototransistor IC DIP-8 Package
