The HPS-167S-L is a high-performance Time-of-Flight (ToF) infrared ranging sensor designed for accurate distance measurements. It features a high signal-to-noise ratio (SNR) and integrates advanced ambient light, temperature, and color compensation algorithms. This ensures fast and precise ranging with an adaptive data output rate between 6 and 54Hz.

Features:

High SNR: Provides clear and reliable distance measurements.
Precision Ranging: Capable of measuring distances up to 40 meters with high accuracy.
Advanced Compensation Algorithms: Integrates ambient light, temperature, and color compensation for enhanced accuracy.
Adaptive Output Rate: Offers a flexible data output rate from 6 to 54Hz.
Robust Design: Enclosed in an ABS+aviation aluminum waterproof case for durability.

Specifications:

1. Model: HPS-167S-L
2. Power Supply: DC 5~15V
3. Maximum Power Consumption: 1.4W
4. Quiescent Power Consumption: 0.1W
5. Storage Temperature: -40~+85
6. Operating Temperature: -10~+55
7. Emitter: VCSEL Laser
8. Emitting Angle: 1.8
9. Maximum Measuring Distance: 40m
10. Minimum Measuring Distance: 0.08m
11. Waterproof: ABS+aviation aluminum waterproof case
12. Adaptive Data Output Rate: 6~54Hz
13. Output Data: Distance, accuracy, signal strength, ambient IR level, temperature
14. Communication Interface: RS485-Modbus

Application:

1. Drone Altitude Holding
2. Drone Soft-Landing
3. Drone Collision Avoidance
4. Security Systems
5. Height Difference Measurement
6. Empty Bay Detection

Package Includes:

1 x ToF Ranging Sensor HPS-167S-L
