The MAX232D is a dual driver/receiver that includes a capacitive voltage generator to supply TIA/EIA-232-F voltage levels from a single 5V supply. Each receiver converts TIA/EIA-232-F inputs to 5V TTL/CMOS levels. These receivers have a typical threshold of 1.3V, a typical hysteresis of 0.5V, and can accept 30V inputs. Each driver converts TTL/CMOS input levels into TIA/EIA-232-F levels. The driver, receiver, and voltage generator functions are available as cells in the Texas Instruments LinASIC library.
Features:
- Operates from a single 5V power supply with 1F charge pump capacitors
- Operates up to 120kbit/s
- Two drivers and two receivers
- 30V input levels
- Low supply current: 8mA Typ.
Package Includes:
1 x MAX232DR TEXAS INSTRUMENTS Transceiver RS232, 2 Drivers, 4.5V-5.5V supply, SOIC-16
| Brand/Manufacturer | Generic |
| Country Of Origin | China |
| Packer / Importer Address | Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India. |
| MRP | Rs. 0 (Inclusive of all Taxes) |
* Product Images are shown for illustrative purposes only and may differ from actual product.
MAX232DR TEXAS INSTRUMENTS Transceiver RS232, 2 Drivers, 4.5V-5.5V supply, SOIC-16
- Product Code: EC-18673
- Availability: 262
-
Rs.57.00
- (Excluding 18% GST)
