  • NE555 Delay Timer Switch Adjustable 0-10 Sec 5V Relay Module

This NE555 Delay Monostable Switch Module item is a timer switch module, based on the NE555 chip, high-performance timing CPU design. The power indicator LED and switch trigger timing indication LEDs. Timing from microseconds to long hours. Applicable to vehicle equipment-delay to prevent car ignition, prevention of high sudden current to burn components and devices.

This is a monostable generator based on the NE555 integrated circuit. It has an adjustable delay time from 0 to 10 seconds using the potentiometer or by changing the capacitance. It is also capable of controlling the device below 220V/10A.


Features and Specifications:-

  • Module based on the NE555 chip.
  • Input Voltage: DC 5V
  • Adjustable time: 0-10 s
  • AC Control voltage: 250V/max. 10A
  • DC Control Voltage: 30V/max. 10A
  • Max. Load: 2200W
  • Precision Pulse Generation / Timing
  • Monostable Operation
  • Standby no power consumption
  • Excellent temperature stability of 0.005%/°C


Package Includes:-

1 x NE555 Delay Timer Switch Adjustable 0-10 Sec 5V Relay Module

Brand/Manufacturer
Country Of Origin
Packer / Importer Address Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India.
MRP Rs. 70.8 (Inclusive of all Taxes)
Write a review
Please login or register to review

* Product Images are shown for illustrative purposes only and may differ from actual product.

NE555 Delay Timer Switch Adjustable 0-10 Sec 5V Relay Module

  • Product Code: EC-11627
  • Availability: 312
  • Rs.62.00
  • (Excluding 18% GST)
