This is 7mm AS150 Anti Spark Self Insulating Bullet Connector featured with an insulated tip to stop big sparks from higher voltage applications. This coupled with the plastic self-insulating shroud offers a safe and effective connector package with no shrink tube needed.
Nowadays, Almost all above 550 class RC helicopter are using 12S Lipo even up to 14S Lipo for Power System. One of the most annoying problems is the Sparking during connecting or while Operating the 12S Lipo, Because sparking will damage the surface of the connector & cause bad contact! This AMASS AS150 Anti Spark Self Insulating Gold Plated Bullet Connector bring you the solutions!
Features:
- Mechanical mounting for cable
- Electrical mounting soldered
- Patented anti-spark design
- Open side for easy soldering
- Low resistance cladding
- Reusable threaded end design, easy to insert/take off from protect the case
- Tightening ring on a Female side to prevent disconnection after long time use
Package includes:
1 x AS150 Anti Spark Self Insulating Gold Plated Bullet Connector (1 Pair)
Specifications:
| Brand | Amass |
| Allowed Wire Size (AWG) | 8 ~ 6 |
| Gender | Mail-Female Pair |
| Rated Operating Voltage (VDC) | 500 |
| Current Handling Capacity (A) | 150 |
| No. of Contact Points | 1 |
| Connector Type | AS150 |
| Contact Material | Brass |
| Body material | Polymide |
| Contact Plating | Gold flash |
| Color | Black and Red |
| Weight (gm) | 8 each |
| Operating Temperature Range (°C) | -20 to 120 |
| Flammability Rating | UL94V-0 |
| Brand/Manufacturer | Generic |
| Country Of Origin | China |
| Packer / Importer Address | Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India. |
| MRP | Rs. 565.22 (Inclusive of all Taxes) |
* Product Images are shown for illustrative purposes only and may differ from actual product.
AS150 Anti Spark Self Insulating Gold Plated Bullet Connector - 1 Pair
- Product Code: EC-7291
- Availability: 438
-
Rs.489.00
- (Excluding 18% GST)
