Hongfa 24V 8A DC HF115F/024-2HS4 6-Pin DPST PCB Mount Power Relay


Features:

  • Low height: 15.7 mm
  • 16A switching capability
  • 5kV dielectric strength (between coil and contacts)
  • Creepage distance: 10mm
  • Meeting VDE 0700, 0631 reinforce insulation
  • Product in accordance to IEC 60335-1 available
  • Sockets available
  • Plastic sealed and flux proofed types available


Specifications:

  • Type :HF115F/024-2HS4
  • Switching Current (A,Res.load) : 8A
  • Contact arrangement : 2 Form A
  • Coil version : single contact
  • Terminal Type : PCB
  • Mounting : PCB-THT
  • Construction : Plastic sealed
  • Terminals : 5.0mm 2 pole 8A
  • Contact material : AgCdO
  • Sort : Standard
  • Coil voltage : 24
  • Coil power: Approx 0.4W
  • Insulation standard : Class B
  • Coil voltage form : DC
  • Rated voltage(V) : 250VAC
  • Volume(mm³) : 29.0×12.7×15.7 (mm)


Package Includes:

1 x Hongfa 24V 8A DC HF115F/024-2HS4 6-Pin DPST PCB Mount Power Relay
