LI120-20B12R2S is Mornsun AC-DC converter series featuring a cost-effective, energy efficient green power supply solution for standard DIN-rail mounting. The products offer a high level of stability and immunity to noise for industrial control equipment, machinery, and other industrial equipment in a variety of harsh environments. These light weight AC-DC converters have an extremely compact design and the standard rail installation for space saving. With good EMC performance, compliant with international UL61010, UL508, EN/BS EN 62368 standards for EMC and safety.
Key Specifications
Type | DIN Rail Single Output |
Output Power | 120W |
Series | LI120-20B |
Part Number | LI120-20B12R2S |
Mount | DIN-Rail |
IP Level | Non-Waterproof |
Output Voltage | 12V |
Output Current | 10A |
Features
- Universal 90 - 264VAC or 127 - 370VDCInput voltage
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range: -20℃to+60℃
- High I/O isolation test voltage up to 4000VAC
- Low ripple & noise
- Output short circuit, over-current, over-voltage, over-temperature protection
- DIN rail TS-35/7.5 or 15 mountable
- Ultra slim design: suitable for small chassis and narrow space installation
- Safety according to UL61010, UL508
Download DATASHEET :
Brand/Manufacturer | Generic |
Country Of Origin | China |
Packer / Importer Address | Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India. |
MRP | Rs. 0 (Inclusive of all Taxes) |
* Product Images are shown for illustrative purposes only and may differ from actual product.
LI120-20B12R2S Mornsun SMPS - 12V 10A 120W AC/DC DIN Rail Power Supply
- Product Code: EC-10632
- Availability: Out Of Stock
-
Rs.2099.00
- (Excluding 18% GST)
