The power of Raspberry Pi 4 in a compact form factor for deeply embedded applications. Raspberry Pi Compute Module 4 incorporates a quad-core ARM Cortex-A72 processor, dual video output, and a wide selection of other interfaces. Available in 32 variants, with a range of RAM and eMMC Flash options, and with or without wireless connectivity.

Raspberry Pi Compute Module 4 has undergone extensive compliance testing and meets the standards required in many countries. You can find all compliance information and regional certificates at raspberrypi.org/compliance.


Features:

  1. Broadcom BCM2711 quad-core Cortex-A72 (ARM v8) 64-bit SoC @ 1.5GHz
  2. H.265 (HEVC) (up to 4Kp60 decode), H.264 (up to 1080p60 decode, 1080p30 encode)
  3. OpenGL ES 3.0 graphics
  4. Options for 1GB, 2GB, 4GB or 8GB LPDDR4-3200 SDRAM (depending on variant)
  5. Options for 0GB (Lite), 8GB, 16GB or 32GB eMMC Flash memory (depending on variant)
  6. Option for fully certified radio module
  7. 2.4 GHz, 5.0 GHz IEEE 802.11 b/g/n/ac wireless
  8. Bluetooth 5.0, BLE
  9. On-board electronic switch to select either external or PCB trace antenna

Package Includes:

1 x Raspberry Pi Compute Module 4 with 4GB RAM 32GB eMMC Wireless



Specifications :-

Model

Raspberry Pi Compute Module 4 4GB RAM 32GB eMMC Wireless

Processor

Broadcom BCM2711 quad-core Cortex-A72 (ARM v8) 64-bit SoC @ 1.5GHz

RAM

4GB LPDDR4-3200 SDRAM

Connectivity

1 PCIe 1-lane Host, Gen 2 ( 5 Gbps )
1 USB 2.0 port ( highspeed )
2.4 GHz, 5.0 GHz IEEE 802.11 b/g/n/ac wireless
Bluetooth 5.0, BLE

Operating Power

5VDC

Video

Dual HDMI interface (up to 4Kp60 supported)
2-lane MIPI DSI display interface
2-lane MIPI CSI camera interface
4-lane MIPI DSI display interface
4-lane MIPI CSI camera interface

Multimedia

H.265 (4Kp60 decode)
H.264 (1080p60 decode,1080p30 encode);
OpenGL ES 3.0 graphics

Length (mm)

55

Width (mm)

40

Height (mm)

2.4


Brand/Manufacturer Raspberry Pi
Country Of Origin UK
Packer / Importer Address Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India.
MRP Rs. 10913.82 (Inclusive of all Taxes)
