This SMA male to female Pigtail RF antenna is used widely for router, booster, and WLAN Wi-Fi Antenna conversion. The antenna adapter can connect your phone to the antenna to provide better reception in no signal areas. High-frequency low-loss antenna extension cord. RG316 military standard Teflon silver plated wire feeder with acid corrosion resistant high temperature and other characteristics.
Features :
- High-Quality SMA Connectors On Both Ends
- High efficiency
- Uses RG316 Coaxial Cable
Package Includes :
1 x SMA Male to Female Pigtail RF Antenna 10 cm
Specifications :-
| Metal | copper |
| Cable length | 10 cm |
| Impedance | 50 Ohm |
| Application | RF |
| Type | SMA |
| Gender | Male to Female |
| Frequency Range | DC-6GHz |
| VSWR | 1.5 Max |
| Insertion Loss | 1.8db |
| Insulation Resistance | 5000M |
| Power Handing | 2W |
| Working Temperature | -40C to +85C |
| Brand/Manufacturer | Generic |
| Country Of Origin | China |
| Packer / Importer Address | Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India. |
| MRP | Rs. 160.48 (Inclusive of all Taxes) |
* Product Images are shown for illustrative purposes only and may differ from actual product.
RG316 Coaxial Cable 10cm Pigtail WLAN Network RF Antenna
- Product Code: EC-6003
- Availability: 1
-
Rs.70.00
- (Excluding 18% GST)
