The Arducam monochrome (B&W) global shutter 1280800 resolution OV9281 camera module is mainly designed for Raspberry Pi boards, and it can be connected directly to RPis CSI-2 camera interface without additional hardware.
The sensors global shutter and excellent low-light sensitivity allow it to be used for any application that needs gesture detection, head, and eye tracking, and depth and motion detection.
Features:
- Monochrome global shutter Camera Module with M12 Mount lens directly inserts to CSI slot on Raspberry Pi. Support Raspberry Pi 4, Pi 3/3B+/3A+, CM3/3+, Pi Zero, and more.
- The Raspberry Pi has recently updated its firmware with V4L2 camera drivers, which adds support including for OV9281.
Package Includes:
1 x Arducam OV9281 1MP Global Shutter Monochrome NoIR Camera Module with M12 Mount lens for Raspberry Pi 4-3B-3
Specifications :-
| Sensor | Monochrome global shutter OV9281 |
| Pixel Size | 3 m x 3 m |
| Optical Size | 1/4 inch |
| Focusing Range | 30mm ~ infinite |
| IR Sensitive | No IR filter, sensitive to IR |
| Output interface | 2-lane MIPI serial output |
| Output formats | RAW8/10 |
| Lens | Default low distortion M12 lens |
| Brand/Manufacturer | Generic |
| Country Of Origin | China |
| Packer / Importer Address | Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India. |
| MRP | Rs. 5025.62 (Inclusive of all Taxes) |
* Product Images are shown for illustrative purposes only and may differ from actual product.
Arducam OV9281 1MP Global Shutter Monochrome NoIR Camera Module with M12 Mount lens for Raspberry Pi 4-3B-3
- Product Code: EC-9107
- Availability: 4
-
Rs.5659.00
- (Excluding 18% GST)
