The MG958 High Torque Digital Metal Gear Servo is the best choice if you need higher torque than 15KG. It provides an excellent performance for RC-cars from 10 to 6 scale truggy monster and 30cc 60cc airplanes. Its shaft is upgraded to aluminum 6061-T6. It is stronger and lighter than copper. The product configure table is provided in the attachments. Please refer to it to get more information regd. the dimensions of the product.


Wire Description:-

RED Positive

Brown Negative

Orange Signal


Features:

  1. Servo arms & screws included and fit with Futaba servo arm
  2. CE & RoHS approved
  3. Servo case: Alloy case in the middle
  4. Gear Type: Metal gear
  5. Bearing: Double ball bearing
  6. Servo wire length: 32cm
  7. Servo Plug: JR (Fits JR and Futaba)

Additional information

Operating Voltage (VDC)

4.8 ~ 6

Operating Temperature (C)

0 to 55

Stall Torque @ 4.8V (Kg-Cm)

18

Stall Torque @6.6V (Kg-Cm)

20

Operating Speed @4.8V

0.18sec/60

Operating Speed @6.6V

0.15sec/60

Current draw (at idle)

10mA

Current draw (at no load)

170mA

Stall current draw

1600mA

Servo wire length

32 cm

Servo Plug

JR (Fits JR and Futaba)

Bearing

Double ball bearing

Gear Type

Metal gear

Servo case

Alloy case in the middle

Length (mm)

54.2

Width (mm)

20

Height (mm)

47.8

Weight (gm)

68


Package Includes:

1 x Tower Pro MG958 Digital High Torque Metal Gear Servo Motor
