  • GT2205 2300KV Brushless DC Motor - Black Cap (CW Motor Rotation)

This GT2205 2300KV Brushless DC Motor is good quality, light-weight multirotor motor with a very nice design both aesthetically and in terms of build quality.

This Brushless DC Motor is very smooth and the tolerances are very tight. It comes with strong c-clip for reliable operation.

The GT2205 2300KV Brushless DC Motor has curved high-temperature N52 magnets and quality proven bearings to improve the operational characteristics of the motor.

The only drawback of this motor is the problem with self-cooling technology. It shows the lack of exposed fins which are really important for cooling purpose.

As we have tested this GT2205 2300KV BLDC motor for its abilities, we have no doubt that it will definitely answer the need for serious makers and pilots of drone racers everywhere.


Features :

  1. The build quality on these is really top notch.
  2. The motor is extremely smooth
  3. The motor weighs around 35 grams.
  4. Use of very strong c-clip makes the motor durable.
  5. Thin, wide and curved magnets for unique flight characteristics.


Package Includes :

1 x GT2205 2300KV Brushless DC Motor

4 x Socket Head Cap (Allen) Bolts for motor fitting



Specifications :-

Model

GT2205

Motor KV (RPM/V)

2300

No-Load Current

0.6 A @10V

Max Power (W)

495

Current Handling Capacity

15 ~ 20 A

Max. Efficiency Current

30 A

Maximum Efficiency

>81%

Internal Resistance(m)

65

LiPO Batteries

3 ~ 4 Cell

ESC

40 ~ 60 A

Propeller

5 inch

Shaft Diameter (mm)

4

Weight (gm)

35



Brand/Manufacturer Generic
Country Of Origin China
Packer / Importer Address Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India.
MRP Rs. 1060.82 (Inclusive of all Taxes)
