This is DSO138 2.4 TFT Handheld Pocket-size Digital Oscilloscope Kit. This DSO138 digital oscilloscope kit adopts ARM Cortex-M3 processor and with 2.4-inch TFT screen.

Its easy and reliable for circuit operation. It can display frequency, period, pulse width, duty ratio, MAX./MIN./AVG./Peak-Peak/virtual values.

This boost converter is a great match for DSO138 oscilloscope kit. It can be connected directly to the DSO138 motherboard(not included), make DSO138 oscilloscope to be a portable oscilloscope for better use.


Features :

  1. This kit uses ARM Cortex-M3 processor (STM32F103C8), and includes a 2.4-inch color TFT display screen, can be used as the ARM test development board.
  2. Can be secondary development on the basis of this kit, for example, it can be changed to Milli voltmeter, data loggers.
  3. Adjustable vertical displacement, and with instructions.
  4. With automatic, regular and one-shot modes, easy to capture the moment waveform.
  5. Available rising or falling edge trigger.
  6. Observable previous trigger waveform (negative delay).
  7. Can freeze at any time waveform display (the HOLD function).
  8. Comes 1Hz /3.3V square wave test signal source.
  9. With waveform parameter digital display, including frequency, period, pulse width, duty ratio, MAX./MIN./AVG./Peak-Peak/virtual values.


Package Includes :

1 x DSO138 DIY Digital Oscilloscope Kit.

1 x Probe.


Additional information

Input Supply Voltage (VDC)

9

Input Impedance ()

1M

Maximum Real-time Sampling Rate

1Msps

Sampling Buffer Depth

1024 bytes

Analog Bandwidth

0-200KHz

Vertical Sensitivity

10mV / Div 5V / Div (1-2-5 progressive manner)

Accuracy

12Bit

Coupling Modes

DC / AC / GND

The Horizontal Time Base Range

10s / Div 50s / Div (1-2-5 progressive manner)

Length (mm)

118

Width (mm)

77

Height (mm)

19

Weight (gm)

130

Shipment Weight

0.225 kg


Brand/Manufacturer Generic
Country Of Origin China
Packer / Importer Address Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India.
MRP Rs. 1858.5 (Inclusive of all Taxes)
