STMicroelectronics Expansion Board IPS161HF is an evaluation board designed for testing and evaluating the IPS161HF IC, a monolithic power switching controller, which provides high voltage, high current, and low dropout voltage. The board is compatible with the STM32 Nucleo development board, allowing users to quickly test and develop applications using the STM32 microcontroller. The IPS161HF board features a built-in power supply and power MOSFETs, enabling the evaluation of the IPS161HF in real-world applications.
Features:
- Industrial digital output expansion board based on IPS161HF for STM32 Nucleo
- Based on IPS161HF single high-side switch
- Application board operating range from 12V to 33V, 0 to 0.7A
- Extended voltage operating range (J1 open) up to 60V
- Green LED for output ON/OFF status
Package Includes:
1 x STMicroelectronics Expansion Board, IPS161HF, STM32 Nucleo Development Board
| Brand/Manufacturer | Generic |
| Country Of Origin | China |
| Packer / Importer Address | Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India. |
| MRP | Rs. 0 (Inclusive of all Taxes) |
* Product Images are shown for illustrative purposes only and may differ from actual product.
STMICROELECTRONICS Expansion Board, IPS161HF, STM32 Nucleo Development Board
- Product Code: EC-22044
- Availability: Out Of Stock
-
Rs.3563.00
- (Excluding 18% GST)
