Industrial Isolated USB To 4-Ch RS232 Converter, USB To Serial Adapter, Original FT4232HL Chip, Mac / Linux / Android / Windows Multi-OS Compatible, Wall-Mount Support

USB TO 4CH RS232 is an industrial USB to RS232 isolated converter, featuring the original FT4232HL. It has onboard protection circuits such as built-in power isolation, ADI magnetical isolation, and TVS diode. With an aluminum alloy case, USB TO 4CH RS232 offers simple operation, zero-delay automatic transmission and reception conversion, and boasts characteristics such as fast, stable, reliable, and safe communication, suitable for industrial control applications with various communication requirements.

Features:

1. Adopts original FT4232HL chip, fast communicating, stable and reliable, better compatibility
2. Supports USB to 4-ch isolated RS232, convenient for expanding multiple RS232 industrial serial devices
3. Onboard unibody power supply isolation, provides stable isolated voltage
4. Onboard unibody digital isolation, allows signal isolation, high reliability, strong anti-interference, low power consumption
5. Onboard TVS (Transient Voltage Suppressor), effectively suppress surge voltage and transient spike voltage in the circuit, lightningproof & ESD protection
6. Onboard self-recovery fuse and protection diodes, ensure the current/voltage stable outputs, provide over-current/over-voltage proof, improve shock proof performance
7. Onboard power supply screw terminal, allows 5V~36V DC wide range input
8. 9 LEDs for indicating the power and transceiver status
9. Aluminum alloy enclosure with sand blasting and anodic oxidation, solid and durable

Specifications:

1. Product Type: Industrial USB to RS232 isolated converter
2. Host port: USB
3. Device port: RS232
4. Baud rate: 300bps ~ 921600bps
5. Operating voltage: 5V
6. Transmission distance: about 5m
7. Power supply: 5~36V DC screw terminal
8. Transmission mode: Point-to-point
9. Temperature range: -40 ~ 85
10. Humidity range: 5%RH~95%RH
11. Operating System: MacOS, Linux, Android, Windows 11 / 10 / 8.1 / 8 / 7

Package Includes:

1 x USB TO 4CH RS232

1 x USB type-A to type-B cable ~1.2m

1 x Power adapter
