The 74LS379 is a 4-Bit Register with buffered common Enable. This device is similar to the 74LS175 but features the common Enable rather then common Master Reset.
Features :-
- 8-Bit High Speed Parallel Registers
- Positive Edge-Triggered D-Type Flip Flops
- Fully Buffered Common Clock and Enable Inputs
- True and Complement Outputs
- Input Clamp Diodes Limit High Speed Termination Effects
Specifications :-
- Supply Voltage : 4.75 - 5.25V
- Input HIGH Voltage : 2.0V
- Input LOW Voltage : 0.8V
- Input Clamp Diode Voltage : -1.5V
- Output HIGH Voltage : 3.5V
- Output LOW Voltage : 0.5V
Package Includes :-
1 X 74LS379 Octal D Flip-Flop IC (74379) DIP-14 Package
| Brand/Manufacturer | |
| Country Of Origin | |
| Packer / Importer Address | Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India. |
| MRP | Rs. 41.3 (Inclusive of all Taxes) |
* Product Images are shown for illustrative purposes only and may differ from actual product.
74LS379 Octal D Flip-Flop IC (74379) DIP-14 Package
- Product Code: EC-11118
- Availability: 2097
-
Rs.35.00
- (Excluding 18% GST)
