• LI60-20B24PR2 Mornsun SMPS - 24V 2.5A 60W AC/DC DIN Rail Power Supply

LI60-20B24PR2 is Mornsun’s AC-DC converter featuring a cost-effective, energy efficient solution for standard DIN-rail mounting. The products offer a high level of stability and immunity to noise, compliant with international IEC62368 standards for EMC are safety approved to IEC/EN61000-4, CISPR32, EN55032, UL62368, IEC62368 and EN62368. These light weight AC-DC converters also have an extremely compact design for space saving and are ideal for applications such as industrial control equipment machinery and all kinds of applications in a harsh environment.

Key Specifications


Type DIN Rail Single Output
Output Power 60W
Series LI60-20B
Part Number LI60-20B24PR2
Mount DIN-Rail
IP Level  Non-Waterproof
Output Voltage 24V
Output Current 2.5A


• Universal 85 - 264VAC or 120 - 370VDC Input voltage

• Accepts AC or DC input (dual-use of same terminal)

• Operating ambient temperature range: -40℃ to +70℃

• High I/O isolation test voltage up to 4000VAC

• Industrial product technology design

• Over-voltage class III (Designed to meet EN61558 safety standards)

• Low standby power consumption, high efficiency

• Low ripple & noise

• Output short circuit, over-current, over-voltage protection

• Withstand 300VAC surge input for 5s

• EN62368 safety approved

Detailed Specifications


Input voltage range 85-264VAC; 120-370VDC
Inrush current (max.) Cold start, 60A at 230VAC
Output voltage adjustable range 21.6-29V
Efficiency at 230VAC 90%
Max. capacitive load 40000µF
Input current (max.) 0.8A at 230VAC
Short circuit protection Hiccup, continuous, self-recovery
Over-current protection ≥120% Io, self-recovery
Withstand voltage 300VAC
Working temperature -40 - 70°C
Connection Terminal block
Package dimensions  92.66 x 52 x 58 mm
Weight 175 gm
Cooling method Free air convection
Case material Plastic, heat-resistant (UL94V-0)
MTBF >300000 Hrs
Safety class CLASS II
Safety standards UL62368/EN62368/IEC62368
EMC standards CISPR32/EN55032 CLASS B, CISPR32/EN55032 CLASS B, IEC/EN61000-4-3 10V/m
Certification CE, RoHS
Warranty 3 years

Related Documents:-

LI60-20B24PR2 Datasheet

Brand/Manufacturer Generic
Country Of Origin China
Packer / Importer Address Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India.
