CJMCU9813 Full Color LED RGB I2C Communication Drive Control Module is a full-color LED driver, using CMOS technology and providing 3 constant-current drivers as well as 256-grade modulation output. It adopts a 2-wire transmission scheme (data and clock), and built-in clock regeneration to enhance the transmission distance. it is suitable for driving the transformation of display lighting, character, and animation. P9813 is excellent in performance, clear in visual effect, simple cascade; data transmission stability, anti-interference ability, and other characteristics.
Specifications :
- IC input voltage: 5V-6.5V.
- Built-in LDO: 4.5V regulator output.
- Three-way drive: each drives current 0-45ma.
- Built-in ring oscillator(1.2MHZ) to support ongoing FREE-RUN modulation output.
- Maximum clock frequency: 15MHZ.
Package Includes :
1 x CJMCU9813 Full Color LED RGB I2C Communication Drive Control Module.
1 x Header set (Without soldered).
Specifications :-
| Input Voltage (Volt) | 4.5 -7.5 |
| Clock Frequency (MHz) | 1.2 |
| Model | CJMCU-9813 P9813 |
| Dimensions (mm) | 24 x 15 x 4 |
| Weight (gm) | 3 |
| Brand/Manufacturer | Generic |
| Country Of Origin | China |
| Packer / Importer Address | Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India. |
| MRP | Rs. 230.1 (Inclusive of all Taxes) |
* Product Images are shown for illustrative purposes only and may differ from actual product.
CJMCU9813 Full Color LED RGB I2C Communication Drive Control Module
- Product Code: EC-6531
- Availability: Out Of Stock
-
Rs.193.00
- (Excluding 18% GST)
