Raspberry Pi released an official 48W (8V DC, 6A) power supply, designed for use with the Raspberry Pi Build HAT. Similarly, it can also power the Raspberry Pi via the BuildHAT.

Power your Raspberry Pi Build HAT projects with the Raspberry Pi Build HAT Power Supply. This 48W power supply will power the Build HAT and connected LEGO Technic motors, as well as your Raspberry Pi computer. Compatible with LEGO Technic motors and sensors included in the LEGO Education SPIKETM Portfolio, the Build HAT combines the power of Raspberry Pi computing with easy building opportunities to help you make creative and robust projects.

Features:

• Input:110-240V AC
• Output:8V DC, 6A
• Cable:1.5M, 16 awg (Premium Quality)

Technical Specifications:

Output

1. Output voltage: +8.0V DC
2. Minimum load current: 0.01A
3. Nominal load current: 6.0A
4. Maximum power: 48.0W
5. Load regulation: 5%
6. Line regulation: 5%
7. Ripple & noise: 200mVp-p
8. Rise time: 100ms maximum to regulation limits for DC outputs
9. Turn-on delay: 3000ms maximum at nominal input AC voltage and full load
10. Protection: Short circuit protection, Overcurrent protection, Overvoltage protection
11. Efficiency: 87.77% minimum (output current from 100%, 75%, 50%, 25%)
12. Output cable: 1.5m 16AWG
13. Output connector: Barrel connector 5.5mm 2.1mm 11mm Centre positive

Input

1. Voltage range: 100-240Vac (rated) 96-264Vac (operating)
2. Frequency: 50/60Hz 3Hz
3. Current: 1.2A maximum
4. Power consumption (no load): 0.1W maximum
5. Inrush current: No damage shall occur and the input fuse shall not blow

Package Includes:

1 x Raspberry Pi Build Hat Power Supply.
